The REL10NM-CY is a non-maintained, surface-mounted cylindrical emergency luminaire offering optimized light distribution for wide spacing in anti-panic areas. It runs a 6W LED with under 0.5W standby power. The 0.4kg fire-retardant fixture features short-circuit protection and a 3-hour Lithium LiFePO4 battery with over-discharge protection.
DETAILS
NON-MAINTAINED SURFACE MOUNT CYLINDRICAL EMERGENCY LUMINAIRE
- Quick fit, cylindrical design for fast installation and maintenance.
- Long life, environmental friendly Lithium Iron Phosphate (LiFePO4) battery.
- Optimal for anti-panic (open area) and escape route lighting applications.
- Surface mount
- Maximum efficiency and perfect light distribution that result to very wide spacing thus lesser number of emergency luminaires are needed in conformity with relevant standards.
TECHNICAL SPECIFICATION
MODEL NO: REL10NM-CY
- Mode of Operation: Non-Maintained
- Lamp: 6W White LED
- Rated Duration: 3 Hours
- Mains Supply: 220-240 Volts, 50-60Hz
- Power Consumption: <0.5W
- Battery: High Temperature Lithium LiFePO4
- Charger: Constant current / Constant voltage, short circuit protected
- Charge Monitor: LED
- Test Facility: Momentary Test Switch
- Safety Features: Low battery voltage cut off to prevent over discharge
- Fitting Construction: Injection moulded with fire retardant (UL94), high impact PC material
- Weight: Approx. 0.4kg
- Standards / Compliance: SS IEC 60598-2-22, SS 563, CB, IEC 61347-2-7, IEC 61347-2-13, IEC 62384, IEC 60598-1
