The REL10NM-CU is an all-in-one, compact recessed emergency luminaire optimal for anti-panic and escape route lighting. It operates with an efficient 6W white LED drawing under 0.5W. The 0.3kg fire-retardant fixture features short-circuit protection, multi-standard compliance, and a 3-hour backup battery with automatic low-voltage over-discharge prevention.
DETAILS
NON-MAINTAINED COMPACT RECESS EMERGENCY LUMINAIRE
- All in One Compact design for fast installation and easy maintenance
- Long life, environmental friendly Lithium Iron Phosphate (LiFePO4) battery
- Low heat generation, ensure long and reliable service life
- Low battery voltage cut-off with latch function, to eliminate battery over discharge
- Charge LED indicator and test switch
- Optimal for anti-panic (open area) and escape route lighting applications
- High quality, long life LED module
- Energy savings, extra low standby power consumption
- Recess mount
TECHNICAL SPECIFICATION
MODEL NO: REL10NM-CU
- Mode of Operation: Non-Maintained
- Lamp: 6W White LED
- Rated Duration: 3 Hours
- Mains Supply: 220-240 Volts, 50-60Hz
- Power Consumption: <0.5W
- Battery: High Temperature Lithium LiFePO4 / High Temperature Nickel Cadmium
- Charger: Constant current / Constant voltage, short circuit protected
- Charge Monitor: LED
- Test Facility: Momentary Test Switch
- Safety Features: Low battery voltage cut off to prevent over discharge
- Fitting Construction: Injection moulded with fire retardant (UL94), high impact PC material
- Weight: Approx. 0.3kg
- Standards / Compliance: SS IEC 60598-2-22, SS 563, CB, IEC 61347-2-7, IEC 61347-2-13, IEC 62384, IEC 60598-1
